Control Panel Setting
On/Off Button
The Button indicated to start or off (pause) the therapy session.
ELECTRON Button
This button selects ELECTRON therapy, which can be performed in Manual Mode with a choice of 2000V, 6000V, 11000V, or 14000V. The voltage and time for AUTOMODE are preset.
COSMOTRON Button
This button selects COSMOTRON therapy, which can be performed in Manual Mode with a choice of 5000V, 9000V, or 13000V. The voltage and time for AUTOMODE are preset.
NEUTRON Button
This button selects NEUTRON therapy,which can be performed in Manual Mode with a choice of 3000V, 8000V, or 12000V. The voltage and time for AUTOMODE are preset.
AUTOMODE Button
Press the AUTOMODE button to enter the AUTOMODE programme. Press the ELECTRON button once to select AU1 and twice to select AU2. Press the COSMOTRON button once to select AU3 and twice to select AU4. Press the NEUTRON button once to select AU5 and twice to select AU6. While still in the AUTOMODE programme, press the TIME button to switch between AU1 and AU11, AU2 and AU12, AU3 and AU13, AU4 and AU14, AU5 and AU15, and AU6 and AU16.
TIME Button
This button is used to select the therapy duration, with available options of 30 minutes, 45 minutes, 60 minutes, 90 minutes, and 2 hours. The duration for AUTOMODE is preset and cannot be alter
VOLTAGE Button
Press the VOLTAGE button to select the appropriate voltage after choosing your desired Manual therapy mode type: either ELECTRON (2000V, 6000V, 11000V, or 14000V), COSMOTRON (5000V, 9000V, or 13000V), or NEUTRON (3000V, 8000V, or 12000V).The voltage for AUTOMODE cannot be set, as it is present.
HERTZ Button
A single press cycles every 3 seconds through 40–120 Hz, repeating. Subsequent presses (2nd, 3rd, 4th) select shorter cycles: 50–90 Hz, 100–120 Hz, and a fixed 120 Hz output. Each pattern repeats from its start point.
MICROTRON Button
The MICROTRON features an AUTOMODE with both preset voltage and time settings. To use the Magic Pen, press the MICROTRON button once to activate Pen 1, twice for Pen 2, three times for Pen 3, or four times to initiate the 8-hour SLEEP program, with each program repeating from its starting point
TEST Button
This button indicates the presence of electro-potential therapy. Press the button and point the remote control correctly towards your body or the therapy pad; the light will blink and a beeping sound will be emitted.
MUTE Button
Pressing this button on the control panel or remote produces an audible beep. This sound also occurs when each therapy session ends. You can deactivate this alert by pressing the button, and reactivate it again if required
AU1 Button (this setting is only applicable for the Japan language version)
This button selects COSMOTRON therapy, which can be performed in Manual Mode with a choice of 5000V, 9000V, or 13000V. The voltage and time for AUTOMODE are preset.
AU3 Button (this setting is only applicable for the Japan language version)
Pressing the AU3 button cycles through the AUTOMODE programme: once for AU3, twice for AU4, three times for AU13, and four times for AU14. A subsequent press returns the selection to AU3 mode.
AU5 Button (this setting is only applicable for the Japan language version)
Pressing the AU5 button cycles through the AUTOMODE programme: once for AU5, twice for AU6, three times for AU15, and four times for AU16. A subsequent press returns the selection to AU5 mode.
